UTx318M Infrared Medium-Range Thermal Monocular
Pairs well with
UTx318M Infrared Medium-Range Thermal Monocular
Description
The UTx318M Infrared Medium-Range Thermal Monocular is engineered for professionals who demand enhanced image quality and dependable performance in the field. Featuring a 400 × 300 thermal sensor, an 18 mm manual-focus lens, and a 944-meter detection range, it delivers crisp thermal imaging for wildlife observation, search and rescue, security patrols, and outdoor surveillance.
Designed for extended outdoor use, the UTx318M combines onboard photo and video recording, Wi-Fi connectivity, and 16GB of internal storage in a rugged IP67-rated housing. A detachable rechargeable battery and lightweight design make it an excellent choice for professionals who need reliable thermal performance throughout long missions.
Key Features
- 400 × 300 Thermal Sensor: Produces detailed thermal imagery with enhanced clarity.
- 18 mm Manual Focus Lens: Optimized for dependable medium-range thermal observation.
- 944 m Detection Range: Detects standard-sized heat signatures at extended distances.
- OLED Display: 0.39-inch OLED display with 1024 × 768 resolution delivers bright, clear viewing.
- Thermal Sensitivity ≤25mK: Detects subtle temperature differences for outstanding image quality.
- Wi-Fi Connectivity: Connects to the Thermal Xplorer app for live viewing and file transfer.
- Photo & Video Recording: Save PNG images and MP4 videos directly to internal memory.
- 16GB Built-In Storage: Store recordings without requiring external memory cards.
- Laser Rangefinder: Integrated laser rangefinder provides additional field capability.
- IP67 Rated: Waterproof and dustproof construction built for demanding environments.
Shipping
Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.
What's Included
- UTx318M Infrared Medium-Range Thermal Monocular
- Carrying case
- USB Type-C charging cable
- Lens cloth
- User manual
Why You'll Love It
The UTx318M offers an ideal combination of image quality, portability, and rugged durability for demanding outdoor applications. Its advanced thermal sensor and excellent thermal sensitivity make it easier to identify heat signatures in challenging environments. Built-in Wi-Fi, recording capabilities, and internal storage simplify documenting observations and sharing data from the field. The detachable rechargeable battery allows for easy power management during extended operations, while the IP67-rated housing stands up to harsh weather and tough working conditions. Whether you're conducting search and rescue missions, wildlife observation, or professional security work, the UTx318M is engineered to deliver dependable thermal performance.
Product Specifications
View Spec Chart
| Thermal Resolution | 400 × 300 |
|---|---|
| NETD | ≤25mK |
| Spectral Response | 8 - 14 µm |
| Pixel Pitch | 12 µm |
| Lens Focal Length | 18 mm |
| Field of View | 14.6° × 11° |
| Focus | Manual |
| Refresh Rate | 50 Hz |
| Detection Range | 944 m |
| Digital Zoom | 2x, 4x, 8x / 1.0x-8.0x continuous |
| Image Format | PNG |
| Video Format | MP4 |
| Laser Rangefinder | Yes |
| Wi-Fi | Yes |
| Mobile App | Thermal Xplorer (Android & iOS) |
| Storage | Built-in 16GB |
| Display | 0.39 in OLED, 1024 × 768 |
| Battery | 3250mAh detachable Li-ion battery (UT-M21) |
| Battery Life | ≥4 hours (Wi-Fi off) |
| Interface | USB Type-C |
| Weight | 357 g |
| Dimensions | 160 × 71.5 × 38.5 mm |
| IP Rating | IP67 |
| Drop Rating | 2 m |
| Operating Temperature | -10°C to 50°C |
| Humidity | 10-95% RH (non-condensing) |
| Certifications | CE |
| Country of Origin | China |
FAQ
What is the maximum detection range?
The UTx318M offers a maximum detection range of 944 meters for a standard-sized target. Actual identification distance varies depending on environmental conditions and target size.
Does the UTx318M support Wi-Fi?
Yes. Built-in Wi-Fi allows the monocular to connect with the Thermal Xplorer mobile app for live viewing and file transfers.
Can I record photos and videos?
Yes. The UTx318M records both PNG images and MP4 videos directly to its built-in 16GB internal storage.
Is the battery removable?
Yes. The UTx318M uses a detachable 3250mAh rechargeable Li-ion battery for convenient charging and replacement.
Is this monocular suitable for harsh outdoor conditions?
Yes. The UTx318M features an IP67-rated housing and has been tested for drops up to 2 meters, making it well suited for demanding outdoor environments.
