Superwinch SX 12K 12,000 lb Synthetic Rope Winch with Wireless & Wired Remote
Pairs well with
FREE Shipping!
Questions? Ask our Experts
Our product specialists are here for you, just leave us a message!
Superwinch SX 12K 12,000 lb Synthetic Rope Winch with Wireless & Wired Remote
Description
The Superwinch SX12SR is engineered to deliver the ideal combination of power, speed, innovation, and proven performance for serious off-road enthusiasts and overlanders. Built around a 6.0 HP sealed motor and 3-stage planetary gearing at a 231:1 ratio, this winch produces 12,000 lbs. of raw pulling power to handle even the most demanding recovery situations. The 3/8" UV-coated synthetic rope is lighter and safer to handle than steel wire, and the aluminum hawse fairlead keeps line feeding smoothly under load. With an IP68 rating for full dustproof and waterproof protection, the SX12SR is built to operate reliably in mud, water, and extreme temperatures from -40 degrees F to 125 degrees F. A patented integrated drum light illuminates the rope and fairlead during low-light recoveries, and the relocatable die-cast aluminum control box gives you the flexibility to mount this winch however your rig demands. Whether you're mounting it on a bumper, hitch, or tucked inside a custom build, the SX12SR has the features and toughness to earn its place on your vehicle.
Key Features
- 12,000 lb Rated Line Pull: Delivers serious pulling power for full-size trucks, Jeeps, Broncos, and heavily built rigs - every Superwinch is tested to meet or exceed its rated pull.
- 6.0 HP Sealed Motor: High-output 12V DC motor with a fully sealed design for protection in wet and dirty conditions.
- IP68 Waterproof & Dustproof: Fully sealed drum, gearbox, and contactor rated IP68 - built to handle stream crossings, deep mud, and dust without issue.
- 80 ft x 3/8" UV-Coated Synthetic Rope: Safer and lighter than steel cable; UV coating extends outdoor lifespan. Aluminum hawse fairlead included.
- Wireless Handheld Remote + 12' Lighted Wired Remote: Both remotes included standard. The wired remote features an integrated lithium-ion rechargeable LED flashlight. Wireless remote allows operation from a safe distance.
- Patented Drum Light: Integrated lighting illuminates the fairlead, rope layers, and spool during operation - a class-leading safety feature for night and low-visibility recoveries.
- Relocatable Die-Cast Aluminum Control Box: Easily repositioned to fit your specific bumper or mounting configuration without permanent modification.
- 3-Stage Planetary Gearing - 231:1 Ratio: Smooth, powerful, and efficient power transfer under full load.
- Rugged Steel Winch Drum: Fully welded steel construction - unlike aluminum drums, steel won't crack or shatter under extreme stress.
- Ergonomic No-Bind Clutch Handle: Pull-and-turn design operates easily with gloves on; clockable gearbox for flexible installation.
- 100% Full-Load Automatic Mechanical Brake: Holds the load securely at any point without relying on the motor.
- Limited Lifetime Mechanical / Limited 7-Year Electrical Warranty: Industry-leading coverage backed by Superwinch's reputation for durability.
Shipping
Ships free! Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.
What's Included
- SX12SR 12,000 lb 12V DC Winch - Graphite Finish
- 80 ft x 3/8" UV-coated synthetic rope (pre-spooled)
- Aluminum hawse fairlead
- Wireless handheld remote
- 12-foot lighted wired remote with integrated lithium-ion rechargeable LED flashlight
- Heavy-duty clevis pinned latched winch hook
- Mounting hardware
Why You'll Love It
Superwinch has built a reputation around winches that actually perform when lives and vehicles are on the line, and the SX12SR carries that legacy forward with class-leading features at a price that outperforms the competition. Off-roaders who have switched from competing brands consistently note the superior fit and finish right out of the box - this is a winch that feels premium before it ever touches a bumper. The patented drum light is a genuinely unique innovation you won't find on other winches at any price, making night recoveries safer and more controlled. The inclusion of both a wireless and a lighted wired remote out of the box means you're ready for any recovery scenario the moment it's mounted. Built and tested to perform from -40 to 125 degrees F, trusted by Jeep, Bronco, and truck enthusiasts across the country, the SX12SR is engineered for years of dependable, hard-working service on and off the trail.
Product Specifications
View Product Specs
| MPN | 1712201 |
|---|---|
| Winch Type | Electric |
| Rated Line Pull | 7,500 - 12,500 lbs |
| Voltage | 12V DC |
| Motor | 6.0 HP, 12V DC |
| Gear System | 3-stage planetary |
| Gear Ratio | 231:1 |
| Clutch | Pull and turn clutch handle |
| Brake System | 100% Full-load holding automatic mechanical brake |
| Rope Material | Synthetic |
| Rope Length | 3/8 in x 80 ft (9.5mm x 24.3m) |
| Fairlead | Aluminum hawse |
| Remote Type | Wired and Wireless (both included) |
| IP Rating | IP68 Waterproof and Dustproof |
| Mounting Bolt Pattern | 10 in x 4.5 in (254mm x 114.3mm) |
| Color / Finish | Graphite metallic powder coat |
| Control Box | Relocatable die-cast aluminum |
| Task Lighting | Patented integrated drum light |
| Drum | Durable fully welded steel drum |
| Winch Hook | Heavy-duty clevis pinned latched |
| Line Speed / Amp Draw | 68 Amps motor draw / 23.4 FPM (7.13 MPM) |
| Drum Diameter | 2.5 in |
| Width | 13.00 in |
| Height | 12.00 in |
| Weight | 62.0 lbs |
| Operating Temperature | -40 degrees F to 125 degrees F |
| Warranty | Limited Lifetime Mechanical / Limited 7-Year Electrical |
FAQ
Does this winch come with both a wireless and wired remote?
Yes - both are included standard. The 12-foot wired remote features an integrated lithium-ion rechargeable LED flashlight, and the wireless handheld remote allows you to operate the winch from a safe distance with a clear line of sight to the recovery. No additional purchases required.
Is synthetic rope better than steel cable for a winch?
Synthetic rope offers several real advantages: it's significantly lighter than steel cable, safer to handle (it doesn't store kinetic energy the way steel does, so it doesn't snap back dangerously if it breaks), and is easier to work with in cold weather or with gloves on. Steel cable offers better resistance to UV exposure, heat, and abrasion in very harsh environments. For most off-road recovery use, synthetic rope is the preferred choice among serious wheelers.
What vehicles is the SX12SR compatible with?
The SX12SR uses a standard 10 in x 4.5 in (254mm x 114.3mm) mounting bolt pattern, which is compatible with most aftermarket off-road bumpers designed for trucks, Jeeps, Ford Broncos, SUVs, and other 4x4 vehicles. It can also be mounted on a hitch receiver with an appropriate hitch-mount winch plate for front-to-rear portability. Always confirm your specific bumper's winch pocket dimensions before ordering.
What does IP68 mean and why does it matter for a winch?
IP68 is the highest standard ingress protection rating for consumer and industrial equipment, meaning the winch is fully protected against dust and against continuous submersion in water. For off-road use this matters enormously - water crossings, mud, rain, and trail debris can all destroy lesser winches. The SX12SR's drum, gearbox, and contactor are all fully sealed to IP68 standards.
Does the winch require professional installation?
Most experienced DIYers can install this winch with basic hand tools. You'll need a compatible bumper or mounting plate with the correct bolt pattern (10 in x 4.5 in), and you'll need to run power leads to your vehicle's battery. Superwinch provides installation documentation to guide the process. If you're not comfortable working with high-current electrical connections, professional installation is recommended.
What is the warranty on the SX12SR?
The SX12SR is backed by Superwinch's Limited Lifetime Mechanical Warranty and a Limited 7-Year Electrical Warranty. This is one of the strongest warranty packages in the winch category and reflects Superwinch's confidence in the build quality of the SX Series.
