Maverick R Trailing Arms

Description

The CT Race Worx Maverick R Trailing Arms are engineered from the ground up for one purpose: powering through rocks with race-proven reliability. Developed and refined over weeks of real-world testing in Johnson Valley, CA alongside professional drivers, these trailing arms are purpose-built to slide over obstacles rather than hang up on them. The result is a set of arms that delivers up to 4" of clearance over stock and 2.5" more clearance in front of the tire to the chassis - a meaningful upgrade for serious off-road competitors and hard-charging trail riders alike.

Every detail has been rethought from the factory design. The sway bar mounting point is raised approximately 2 inches from stock - a change driven directly by testing feedback - and sealed bottom bungs protect brake line mounting points from the elements. Smart shock tabs for sensor mounting and integrated wire management tabs round out a package that is as functional as it is race-ready. Handbuilt in the USA and backed by a no-nonsense lifetime warranty, these trailing arms represent a serious upgrade for any Can-Am Maverick R build.

Key Features

• Race-Proven Design: Engineered from the ground up and tested extensively in Johnson Valley, CA with professional drivers for real-world rock-crawling performance.
• 4" Clearance Over Stock: Provides a maximum of 4" of additional clearance over the stock trailing arm position for dramatically reduced hang-ups.
• 2.5" Front Tire-to-Chassis Clearance: Extra clearance in front of the tire to the chassis allows for better tire placement and fewer obstacles catching the arm.
• Raised Sway Bar Mount: Sway bar mounting point is raised roughly 2 inches from the stock location - the #1 hang-up point identified during testing - for smoother rock navigation.
• Sealed Bottom Bungs: Brake line mounting points feature sealed bottom bungs (M6x1.0) to keep the arm completely sealed and protected from dirt and moisture.
• Smart Shock Tabs: Integrated tabs for shock sensor mounting and wire management keep your electronics organized and protected.
• WSSX14T Uniballs: Wearable items use WSSX14T uniballs at the frame pivot point for reliable, serviceable performance.
• Gravel Guard Provisions: Trailing arms include mounting provisions for gravel guards (gravel guards sold separately).
• Lifetime Warranty: Every set is backed by CT Race Worx's no-BS lifetime warranty.
• Handbuilt in the USA: Each set is handbuilt in Monroe, NC with American craftsmanship and race-level quality control.

Length Options & Which to Choose

• Short: Designed for 2024-2026 Can-Am Maverick R 2-seat models (non-XRC versions). If you're running a standard 2-seat Maverick R from 2024-2026, this is your arm. Available in Bare or powder coat finishes.
• Long: Designed for all 4-seat Maverick R models, 2-seat XRC models, and all Maverick R models from 2027 onward. If you're running an XRC or a MAX (4-seat) in any year, or any 2027+ model, go with the Long arm. Available in Bare or powder coat finishes.

What's Included

• CT Race Worx Maverick R Trailing Arms (pair - Short or Long, per option selected)

Note: Gravel guards are NOT included. These arms have a lead time of roughly 4 weeks or less.

Why You'll Love It

When you're pushing a Can-Am Maverick R through technical rock terrain, the last thing you want is a trailing arm that fights the trail instead of flowing over it. The CT Race Worx Maverick R Trailing Arms were built by people who have been there - tested by pros, refined by real feedback, and handbuilt in the USA to a standard that matches the demands of the most aggressive off-road environments. The raised sway bar mount and increased clearance numbers aren't marketing claims - they're the direct result of weeks of testing that identified exactly where the stock arms fall short.

Backed by a lifetime warranty and made with the kind of attention to detail you'd expect from a race shop, these trailing arms are a confident, long-term investment in your build. Whether you're competing or just sending it on the weekend, CT Race Worx gives you the hardware to run harder and hang up less.
