Maverick R Pro Rock High Clearance Lower A Arms
Description
The CT Race Worx Maverick R Pro Rock High Clearance Lower A Arms are the strongest rock arms built for the Can-Am Maverick R, engineered from over a decade of hard-won experience on the most punishing terrain in the world - including King of the Hammers. Now in their Gen 3 form, these arms incorporate every refinement learned since the Maverick R entered the racing scene, featuring added caster through the lower A arm for improved high-speed stability and a larger cross section to handle brutal rock impacts without hesitation.
Handbuilt in the USA and backed by a lifetime warranty, these arms are a direct upgrade for riders who demand the highest level of protection and performance from their front suspension. From trail riding to all-out racing, the Pro Rock arms are designed to take punishment and keep you moving forward - no compromises, no shortcuts.
Key Features
- Gen 3 Design: Latest generation with added caster and larger cross section over Gen 2 for better handling at speed and superior obstacle resistance.
- Over Double the Stock Caster: Dramatically improved front-end stability at high speeds compared to stock suspension geometry.
- CT Patented Double Shear Spindle Mount: Bolt-on double shear design mounts to stock spindles using 7/8" FK uniballs for unmatched spindle mounting strength.
- 14mm Mounting Hardware: Upgraded 14mm spindle hardware vs. the stock 12mm stud for significantly increased strength at the spindle connection point.
- 3-3/16" Ground Clearance Increase: Industry-leading clearance gain over stock while also accommodating larger aftermarket axles.
- O-Ring Sealed A Arm Bushings: Ultra-durable bushing material paired with 17-4 heat treated stainless steel pins and caps for zero resistance and unrestricted suspension travel.
- Ramped Double-Layered Bash Face: Front bash face is ramped and double-layered to slide over obstacles and prevent hang-ups on the trail or race course.
- Threaded Skid Plate Mounting Bungs: Integrated mounting points for easy skid plate installation.
- Rerouted Brake Lines: Brake lines are repositioned within the arm for added protection against damage.
- Recessed Sway Bar Mount: Front sway bar mounting point is recessed to protect hardware from trail and rock damage.
- Smart Shock Wire Provisions: All arms include wiring provisions for smart shock wires.
- Lifetime Warranty & Made in the USA: Handbuilt in Monroe, NC with a full lifetime warranty backing every arm.
Finish Options & Which to Choose
- Bare: Raw, uncoated metal finish - ideal for riders who plan to apply their own coating or simply want maximum value. A great choice for builders and fabricators who like to customize.
- Semi Gloss Black: A tough, understated finish that complements most UTV builds and holds up well in harsh trail environments. The most popular choice for everyday riders and racers alike.
- Neo Yellow: A bold, high-visibility color that stands out on the trail and pairs perfectly with Can-Am's signature yellow accents. Best for riders who want a factory-coordinated look.
- Legion Red: A striking red finish that adds aggressive style to your build. A great match for custom color schemes and riders who want their machine to turn heads.
What's Included
- Maverick R Pro Rock High Clearance Lower A Arms (pair)
- CT patented bolt-on double shear spindle mount hardware
- 14mm spindle mounting hardware
- 7/8" FK uniballs
- 17-4 heat treated stainless steel bushing pins and caps
- O-ring sealed A arm bushings
Why You'll Love It
CT Race Worx has been building high clearance boxed A arms since 2013, and every generation has been shaped by real-world racing results and hard trail miles - not just a drafting table. These Gen 3 arms represent the pinnacle of that experience, trusted by riders who compete at events like King of the Hammers where failure simply isn't an option. The patented double shear spindle mount is a genuine innovation that sets these arms apart from anything else on the market for the Maverick R. Handbuilt in Monroe, NC, every arm is a product of American craftsmanship and race-proven engineering. Backed by a lifetime warranty, this is a true "buy once" upgrade that will outlast everything you put them through. If you're serious about your Maverick R build, these are the arms to have.
Product Specifications
View Product Specs
| Brand | CT Race Worx |
|---|---|
| SKU | CT-MAVR-2020-0 |
| Generation | Gen 3 |
| Clearance Gain Over Stock | 3-3/16" increase |
| Spindle Mount Hardware | 14mm (vs. stock 12mm stud) |
| Uniball Size | 7/8" FK uniballs |
| Bushing Pin Material | 17-4 heat treated stainless steel |
| Spindle Mount Type | CT patented bolt-on double shear |
| Fitment | 2024-2026 Can-Am Maverick R (Base, MAX, XRC, XRS) |
| Country of Manufacture | USA (Monroe, NC) |
| Warranty | Lifetime |
| Lead Time | Approximately 1-3 weeks |
| Finish Options | Bare, Semi Gloss Black, Neo Yellow, Legion Red |
| Assembly Required | Yes - professional installation recommended |
| Shipping Method | Contact for shipping details; lead time is 1-3 weeks from order |
FAQ
What Can-Am Maverick R models do these arms fit?
These arms are designed to fit the 2024-2026 Can-Am Maverick R in all trims, including the Base, MAX, XRC, and XRS models. If you're unsure about fitment for your specific build, use the fitment verification tool or reach out to us directly before ordering.
What is the difference between Gen 2 and Gen 3 arms?
The Gen 3 arms feature two major upgrades over Gen 2: added caster built into the lower A arm geometry for improved high-speed stability, and a larger cross section tube for increased strength when impacting rocks and obstacles. All generational changes are refinements driven by real racing and trail feedback.
What does the patented double shear spindle mount mean for my build?
The CT patented double shear spindle mount replaces the stock single-shear ball joint design with a bolt-on double shear setup using 7/8" FK uniballs. This distributes spindle loads across two shear points instead of one, dramatically increasing strength at one of the most vulnerable points in the front suspension - especially important in rock crawling and high-impact off-road use.
Do I need to replace my stock spindles to install these arms?
No - these arms are designed to bolt on to your stock Can-Am Maverick R spindles using the CT patented double shear mount. No custom or aftermarket spindles are required, though the arms do accommodate larger aftermarket axles thanks to the 3-3/16" clearance increase over stock.
What is the lead time and how will these ship?
Current lead time is approximately 1-3 weeks as these are handbuilt to order in Monroe, NC. Due to their size and weight, please contact us for specific shipping details for your location. We'll make sure you get accurate freight information before your order ships.
Is professional installation required?
While experienced UTV builders may be comfortable installing these arms at home, professional installation is strongly recommended to ensure proper torque specs, brake line routing, sway bar connection, and suspension alignment. Incorrect installation could compromise handling and safety, so having a qualified shop handle the install is always a good idea.
