DOF Reality P4 PRO Universal Motion Simulator Platform - 4-Axis
Pairs well with
FREE Shipping!
DOF Reality P4 PRO Universal Motion Simulator Platform - 4-Axis
Description
The DOF Reality P4 PRO is the flagship universal motion simulator platform, engineered for those who demand the highest level of realism across racing, flight, and helicopter simulation without compromise. Offering true 4 degrees of freedom - Pitch, Roll, Yaw with rear traction movement, and Heave - the P4 PRO delivers immersive g-force feedback that puts you in the seat of any vehicle or aircraft. All primary components including the seat, steering wheel, pedals, flight controls, and displays move together as a single rigid unit, ensuring consistent and accurate force simulation through every body pressure point.
Built with professional-grade motors and reinforced commercial-grade steel mechanics, the P4 PRO is engineered for long-term reliability and continuous operation, making it equally at home in commercial venues and private simulation rooms. Powered by Sim Racing Studio software, it delivers precise telemetry-driven motion feedback that reproduces surface detail, vibrations, dynamic forces, turbulence, road bumps, elevation changes, and landing forces with exceptional accuracy. Whether you're chasing lap times in iRacing, dogfighting in DCS World, or cruising in Microsoft Flight Simulator, the P4 PRO is the ultimate all-in-one motion platform.
Key Features
- 4 Degrees of Freedom (4-DOF): Full Pitch, Roll, Yaw/Rear Traction, and Heave axes for the most complete motion simulation available in this class.
- Heave Axis: Vertical motion reproduces road bumps, curbs, elevation changes, turbulence, jumps, and landing forces across all simulation types.
- Yaw/Rear Traction Movement: Simulates rear traction loss, coordinated turns, and directional changes for highly realistic racing and flight dynamics.
- 20-Degree Range of Motion: Wide motion envelope across all axes for convincing, full-body immersion.
- Speed and Torque: 75 cm/s (105 degrees/s) motion speed and 28 Nm torque for fast, responsive feedback.
- Commercial-Grade Steel Construction: Built from heavy-duty metal profiles for long-term durability and continuous professional use.
- 440 lb / 200 kg Pilot Weight Capacity: Supports a wide range of users in professional and private settings.
- Sim Racing Studio Powered: Real-time telemetry-driven software compatible with 50+ racing, flight, and helicopter simulator titles including iRacing, Assetto Corsa, F1 25, Gran Turismo 7, DCS, X-Plane 12, and Microsoft Flight Simulator 2024.
- Plug-and-Play Ready: Includes rigid metal rig, integrated power drive motors, 100-240V control unit with USB, SimRacingStudio license, and quick assembly tools - ready to connect to your existing seat and controls.
- Universal Racing, Flight, and Heli Compatibility: One platform that handles every simulation genre at the highest level.
- 1-Year Full Warranty: Comprehensive coverage for peace of mind on your investment.
- Upgradable: Expandable with over 20 available options and accessories including seats, HOTAS mounts, monitor mounts, wind packages, and more.
Shipping
Ships free! Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.
Note: The P4 PRO ships in two boxes due to its size and weight. Box 1: approximately 78 lb (37 x 15 x 11 in). Box 2: approximately 97 lb (32 x 24 x 10 in). Delivery is handled via FedEx or DHL Express door-to-door with full tracking and insurance. Assembly is required upon arrival - the process is straightforward and tools are included. Delivery typically takes 3-4 weeks from order date.
What's Included
- P4 PRO 4-Axis Universal Motion Platform (rigid metal rig for normal and F1 pose)
- Mounts for seat or sliding rails
- Integrated power drive motors
- 100-240V control unit with USB
- SimRacingStudio software license
- All necessary cables
- Quick assembly tools
- 1-year full warranty
Note: Seat, VR headset, steering wheel, pedals, yoke, and game titles are not included and must be purchased separately. The platform supports all standard seat and controller configurations.
Why You'll Love It
The DOF Reality P4 PRO is the choice of serious simulation enthusiasts and commercial venue operators who refuse to settle for anything less than the best. Its 4-DOF motion system delivers a level of physical immersion that transforms familiar sim titles into experiences that feel genuinely real - from the snap of rear traction loss in a hairpin to the lurch of a hard carrier landing. Built from commercial-grade steel with professional motors, this platform is engineered for years of demanding, daily use without losing a step. The included SimRacingStudio license means you're up and running with real telemetry from day one, across a massive library of compatible titles. For private sim builders and professional installation alike, the P4 PRO represents the pinnacle of what a universal motion platform can be - versatile, powerful, and built to last.
Product Specifications
View Product Specs
| Degrees of Freedom | 4 DOF (Pitch, Roll, Yaw/Rear Traction, Heave) |
|---|---|
| Full Platform Motion | Yes |
| Range of Motion | 20 degrees |
| Speed | 75 cm/s (105 degrees/s) |
| Torque | 28 Nm |
| Acceleration | 0.75G Translational / 0.5G Lateral |
| Power Consumption | 1000 Watt (peak) |
| Shipping Box 1 Weight | 78 lb (37 x 15 x 11 in) / 35 kg (94 x 38 x 28 cm) |
| Shipping Box 2 Weight | 97 lb (32 x 24 x 10 in) / 44 kg (80 x 60 x 25 cm) |
| Floor Footprint | 3 x 5 ft, 2 ft H (100 x 150 cm, 60 cm H) |
| Frame Material | Commercial-grade metal profiles |
| Max Pilot Weight | 440 lbs / 200 kg |
| Warranty | Full 1 year |
| Upgradable | Yes - upgradable to P6 |
| Assembly Required | Yes - tools included, straightforward process |
| Shipping Method | FedEx or DHL Express, door-to-door, two boxes |
Compatible Games
- iRacing
- Assetto Corsa, Competizione, and EVO
- Automobilista 1 and 2
- Le Mans Ultimate
- F1 22-25
- Forza Horizon 4 and 5
- Gran Turismo 7 and Sport
- Project CARS 1, 2, 3, PRO
- BeamNG.drive
- rFactor 2
- Wreckfest and Wreckfest 2
- Forza Motorsport (2023) and Forza Motorsport 7
- Microsoft Flight Simulator 2024 (MSFS 2024)
- DCS World
- X-Plane 12
- And many more - 50+ titles supported
Manuals & Guides
FAQ
Does the P4 PRO work with PlayStation and Xbox consoles?
Yes, with some limitations. Consoles operate on closed platforms, and only select games send motion data via UDP over the network - including Gran Turismo 7, GT Sport, Project CARS 1 and 2, Assetto Corsa, F1 series, Forza Motorsport 7, and Forza Horizon 4 and 5. For these games, DOF Reality offers a Console Link (MagicBox) add-on. For full PC compatibility with all supported titles, a gaming PC is recommended.
Does the platform come assembled?
No - the P4 PRO ships in two boxes and requires assembly upon arrival. Assembly tools are included and the process is designed to be straightforward and enjoyable. Assembling it yourself also allows you to customize the fit and layout to your preferences. The platform weighs between 130 and 220 lbs (60-100 kg) fully assembled.
What seat do I need, and is one included?
A seat is not included with the platform. Almost any bottom-mount car seat or racing gaming seat with standard mounting hardware will work. DOF Reality recommends a bucket-style racing seat to keep you secure during high-intensity g-force movements. A lighter seat will generally improve platform performance and responsiveness. Optional seats including Sparco models are available as add-ons.
Does it work with VR headsets?
Yes, the P4 PRO is fully compatible with all VR headsets. When using VR on a motion platform, the platform's movement can affect the VR image. For most users the effect is manageable, but if needed, OpenVR Motion Compensation software can be used to remove platform movement from the VR image. This works with both base-station (outside-in) and inside-out tracking headsets.
What is the difference between the P4 PRO and the P3 or P6?
The P3 offers 3 degrees of freedom (Pitch, Roll, and Yaw/Rear Traction) and is a strong entry into the PRO lineup. The P4 PRO adds a fourth axis - Heave - which adds vertical motion for bumps, curbs, elevation changes, turbulence, and landing forces, significantly enhancing immersion. The P6 goes further with 6 full degrees of freedom including Surge and Sway, offering the most complete motion envelope available. The P4 PRO is upgradable to P6 if you want to expand later.
What software is used and is it included?
The P4 PRO comes with a SimRacingStudio (SRS) software license included. SRS reads real-time telemetry from your simulation games and translates it into precise motion commands for the platform. All necessary cables and motion software are provided. Games themselves are not included and must be purchased separately.
