DOF Reality H4 Hero 4-Axis Flight Motion Simulator Platform
Pairs well with
FREE Shipping!
DOF Reality H4 Hero 4-Axis Flight Motion Simulator Platform
Description
The DOF Reality H4 Hero is a true 4-axis motion simulator platform built for flight sim enthusiasts who demand real physical immersion at home. Unlike traditional fixed or 2-axis setups, the H4 adds Heave to its Pitch, Roll, and Yaw axes - meaning you physically feel vertical G-forces, turbulence, acceleration changes, and altitude drops through your entire body. Built on DOF Reality's decade-plus of experience developing affordable professional-grade motion simulators, the H4 brings commercial flight sim realism into a compact, home-friendly footprint without sacrificing performance.
Constructed from high-strength European commercial-grade steel, the H4 platform moves your seat, flight controls, and pedals together as a single unified unit, delivering accurate force feedback through your body's pressure points rather than just visual cues. It integrates seamlessly with all major flight sim titles - from Microsoft Flight Simulator 2024 and DCS World to X-Plane 12 and IL-2 Sturmovik - as well as all major VR headsets. Whether you're a seasoned flight simmer, a helicopter enthusiast, or a racing sim fan looking for the most immersive at-home experience available, the H4 Hero is the platform that bridges the gap between home setup and professional-grade simulation.
Key Features
- True 4-Axis Motion (4 DOF): Full Pitch, Roll, Yaw/Rear Traction, and Heave - the only at-home simulator with all four axes, including vertical G-force sensation.
- Heave Axis: Feel turbulence, road bumps, jumps, and vertical acceleration changes with high physical precision - something 3-axis platforms cannot replicate.
- 20-Degree Range of Motion: Wide motion envelope at 20 degrees on all axes for convincing tilt, bank, and yaw simulation.
- 50 cm/s Motion Speed (86 deg/s): Fast actuator response ensures motion cues are delivered in real-time sync with your sim software.
- 25 Nm Torque: Powerful integrated motors deliver strong, precise movement even under load.
- 440 lb / 200 kg Pilot Weight Capacity: Supports a wide range of users with commercial-grade structural integrity.
- Compact 3 x 5.2 ft Floor Footprint: Fits in home sim rooms, garages, and dedicated spaces without sacrificing motion performance.
- High-Strength European Steel Construction: Commercial-grade metal profiles engineered for long-term durability and daily use.
- Plug-and-Play Ready: Includes integrated power drive motors, 100-240V control unit with USB, and SimRacingStudio software license - ready to connect and run.
- Universal Compatibility: Works with all major VR headsets, flight sticks, HOTAS setups, racing wheels, pedals, and yoke controllers.
- 1-Year Full Warranty: Covered by DOF Reality's full one-year manufacturer warranty, with upgrade path to H6 available.
- Compatible Games: Supports Microsoft Flight Simulator 2024/2020, DCS World, X-Plane 10/11/12, IL-2 Sturmovik, War Thunder (planes), Elite Dangerous, Star Wars: Squadrons, Prepar3D, and many more.
Shipping
Ships free! Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.
Important shipping note: The H4 platform ships in two heavy-duty boxes (approximately 78 lb and 97 lb) via FedEx or DHL Express with full tracking and insurance. Delivery typically takes 3-4 weeks. Assembly is required upon delivery - all necessary tools are included and the process is straightforward.
What's Included
- H4 motion platform - rigid metal rig for normal and F1 pose
- Mounts for seat or sliding rails
- Integrated power drive motors
- 100-240V control unit with USB
- SimRacingStudio software license
- Quick assembly tools
- All necessary cables
- 1-year full warranty
Note: Seat, VR headset, and controllers (wheel, pedals, yoke, HOTAS, etc.) are not included and must be purchased separately. Games are not included.
Why You'll Love It
The DOF Reality H4 Hero is what serious flight simulation enthusiasts have been waiting for - a platform that finally delivers the sensation of flight through your entire body, not just on a screen. The addition of Heave makes the H4 feel categorically different from any 3-axis setup: you don't just see turbulence, you feel it hit your seat and push into your back. Built from commercial-grade European steel and developed by a company with over a decade of motion simulator expertise, this platform is engineered to hold up through years of daily use without losing precision or reliability.
With its compact footprint, universal compatibility, and plug-and-play design, the H4 fits naturally into any dedicated sim space and works with your existing VR headset, HOTAS, and flight controls right out of the box. The SimRacingStudio license is included, so you're up and flying faster than you'd expect. For anyone who has ever wanted to feel what it's really like to bank into a turn, drop into a valley, or push through turbulence - the H4 Hero is the at-home platform that makes it real.
Product Specifications
View Product Specs
| Degrees of Freedom | 4 DOF (Pitch, Roll, Yaw/Rear Traction, Heave) |
|---|---|
| Full Platform Motion | Yes |
| Range of Motion | 20 degrees |
| Speed | 50 cm/s (86 deg/s) |
| Torque | 25 Nm |
| Acceleration | 0.7G Translational / 0.5G Lateral |
| Power Consumption | 1000 Watt (peak) |
| Floor Footprint | 3 x 5.2 ft / 100 x 150 cm |
| Platform Height | 2 ft / 60 cm |
| Material | Commercial-grade European steel profiles |
| Max Pilot Weight | 440 lbs / 200 kg |
| Shipping Box 1 | 78 lb (37 x 15 x 11 in) / 35 kg (94 x 38 x 28 cm) |
| Shipping Box 2 | 97 lb (32 x 24 x 10 in) / 44 kg (80 x 60 x 25 cm) |
| Power Input | 100-240V with USB control unit |
| Assembly Required | Yes - tools included |
| Warranty | 1 year full warranty |
| Upgradable | Yes - upgradable to H6 |
Manuals & Guides
FAQ
What is the difference between the H4 and the H3?
The H4 adds a fourth axis called Heave to the H3's three axes (Pitch, Roll, Yaw). Heave simulates vertical motion - think turbulence, bumps, jumps, and vertical G-forces. The H4 also uses a more powerful 1000W peak motor system versus the H3's 750W. If you want to physically feel altitude drops and air pockets in addition to banking and turning, the H4 is the upgrade worth having.
Do I need to buy a seat separately?
Yes. The H4 platform includes mounts for a seat or sliding rails, but the seat itself is not included. Almost any standard bottom-mount car or gaming bucket seat will work. DOF Reality recommends a bucket racing seat with a four-to-six point harness to keep you secure during high-G movements. Lighter seats generally improve platform performance.
Does the H4 work with VR headsets?
Yes, the H4 is compatible with all major VR headsets, including Valve Index, HTC Vive, Meta Quest, HP Reverb G2, and Pimax. If you experience visual swimming due to the platform's movement affecting your VR image, you can use OpenVR Motion Compensation software to remove the platform movement from the headset tracking. This is free software and works with both base-station and inside-out tracking headsets.
How long does assembly take?
Assembly is required but is designed to be straightforward and enjoyable. All quick assembly tools are included in the package. The platform ships in two boxes and can be assembled by one person. DOF Reality's support team is available via email or phone to assist with any questions during the build.
What flight sim games are compatible with the H4?
The H4 supports a wide range of flight simulation titles including Microsoft Flight Simulator 2020 and 2024, DCS World, X-Plane 10/11/12, IL-2 Sturmovik series, War Thunder (aircraft only), Elite Dangerous, Star Wars: Squadrons, Lockheed Martin Prepar3D 4.5 and 5, Aerofly FS 2, Silent Wings, Condor 2, and many more. The included SimRacingStudio license handles motion data integration for compatible titles.
Can the H4 be used with PlayStation or Xbox?
Yes, with some limitations. A select few console games - such as Gran Turismo 7, Project CARS, Assetto Corsa, F1, and Forza - send motion data over UDP and can work with a DOF Reality Console Link add-on. For broader console game support, additional accessories may be required. PC is the recommended platform for the fullest game compatibility.
Is the H4 upgradable to a 6-axis platform?
Yes. The H4 is designed with an upgrade path to the DOF Reality H6, which adds Surge and Sway axes for full 6-DOF motion. This future-proofing means your investment in the H4 is not a dead end - you can scale up your simulation experience as your budget allows.
