DEEP Robotics Lynx M20 Pro Industrial Wheel-Legged Robot
Description
The DEEP Robotics Lynx M20 Pro is an industrial-grade wheel-legged quadruped robot engineered for the most demanding environments on earth. As part of the world's first wheeled-legged robot platform built specifically for hazardous industrial operations, the M20 Pro fuses the speed of wheeled mobility with the agility of legged locomotion - giving operators a single platform capable of navigating mountains, wetlands, tunnels, debris-strewn ruins, and beyond. Designed for power inspection, emergency response, logistics, search and rescue, and scientific exploration, it bridges the gap between manual labor and heavy machinery.
At 36kg with battery, the M20 Pro is portable by a single operator and fits through 50cm clearances, yet delivers a 36kg payload capacity on standard terrain and a maximum payload of 100kg. Dual 128-channel LiDAR units provide a full 360°x95° field of view at over 1.1 million points per second, enabling autonomous navigation and omnidirectional obstacle avoidance even in complete darkness thanks to front/rear bidirectional lighting. IP67-rated and operational from -30°C to 55°C, this robot is truly built to go where people cannot.
Key Features
- Wheel-Legged Hybrid Locomotion: Combines wheeled speed with legged agility for unmatched versatility across terrain types including stairs, slopes, rubble, wetlands, and tunnels.
- 36kg Payload / 100kg Max Load: Handles substantial payloads on standard terrain with a maximum load capacity of 100kg, enabling real mission-critical equipment transport.
- Dual 128-Channel LiDAR: Two 128-line LiDAR sensors with 360°x95° FOV and ~1,152,000 pts/s deliver precise real-time environmental mapping and autonomous obstacle avoidance.
- IP67 Protection Rating: Fully dust-tight and protected against water immersion - built to operate in rain, mud, and wet industrial environments without compromise.
- -30°C to 55°C Operating Range: Performs reliably in extreme cold and heat, from arctic inspection sites to scorching industrial facilities.
- Up to 5-Hour Runtime / 20km Range (Unloaded): Hot-swappable dual battery system with 3.5-5 hour unloaded endurance and 2.5-3.5 hours under payload, minimizing downtime in the field.
- 9m/s Lab-Tested Top Speed: Capable of up to 9m/s in lab conditions (safety-limited to 3m/s in user mode), making it one of the fastest platforms in its class.
- SLAM Mapping & Autonomous Navigation: Onboard SLAM enables full autonomous navigation and localization without GPS dependency, including omnidirectional obstacle avoidance.
- Triple Octa-Core Industrial Processors: Powered by 3 x octa-core 64-bit industrial processors (16GB + 128GB each) for real-time sensor fusion and AI-driven decision making.
- OTA Updates & Modular Expansion: Supports over-the-air firmware upgrades and modular payload expansion for evolving mission requirements.
- 100cm Max Single-Step Obstacle Height: Clears obstacles up to 100cm high and 45° slopes, with a max stair height of 30cm for multi-story navigation.
Shipping
Ships free! Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.
What's Included
- DEEP Robotics Lynx M20 Pro wheel-legged robot
- Battery (included, hot-swappable dual battery system)
- Wide-angle cameras x2
- Dual 128-channel LiDAR units x2
Why You'll Love It
The Lynx M20 Pro represents a genuine leap forward in autonomous industrial robotics - trusted by organizations worldwide for inspection, rescue, and exploration missions in environments too dangerous or inaccessible for human operators. Its combination of IP67 protection, extreme temperature tolerance, and true autonomous navigation makes it a platform that facilities managers, emergency response coordinators, and research teams can depend on mission after mission. The hot-swappable dual battery system means you're never stuck waiting for a recharge during time-critical operations. With OTA upgrade capability, your M20 Pro evolves with new features and capabilities as DEEP Robotics continues to advance the platform. For organizations that demand reliability, adaptability, and cutting-edge embodied intelligence in a single deployable unit, the Lynx M20 Pro is the standard by which all others are measured.
Product Specifications
View Product Specs
| Dimensions (Standing) | 820mm x 430mm x 570mm |
|---|---|
| Weight (with battery) | 36kg |
| Effective Payload (standard terrain) | 36kg |
| Maximum Payload Capacity | 100kg |
| Operating Time (no payload) | 3.5-5 hours |
| Range (no payload) | 16-20 km |
| Operating Time (with payload) | 2.5-3.5 hours |
| Range (with payload) | 12-15 km |
| Single Battery Charging Time | 1.5 hours |
| Max. Tested Speed | 9m/s (safety-limited to 3m/s in user mode) |
| Max. Operating Speed | 2m/s |
| Max. Stair Height | 30cm |
| Max. Single-Step Obstacle Height | 100cm |
| Max. Slope | 45° (lab-tested; actual performance varies by surface) |
| Computing Power | 3 x octa-core 64-bit industrial processors (16GB + 128GB) |
| LiDAR | x2, 128-channel, 360°x95°, ~1,152,000 pts/s |
| Wide-Angle Cameras | x2 |
| Ingress Protection Rating | IP67 |
| Operating Temperature | -30°C to 55°C |
| Electrical Interfaces | Power input (24V/72V), Gigabit Ethernet, USB 3.0 |
| Functional Features | SLAM Mapping & Localization, Autonomous Navigation, Omnidirectional Obstacle Avoidance, Hot-Swappable Dual Battery, RF Image Transmission, OTA Upgrades, Autonomous Charging (Optional) |
FAQ
What industries is the Lynx M20 Pro designed for?
The Lynx M20 Pro is purpose-built for industrial applications including power and utilities inspection, emergency rescue and response, tunnel and underground operations, metal and mining environments, construction site monitoring, and scientific research. Its IP67 rating and extreme temperature tolerance make it suitable for virtually any hazardous or remote deployment scenario.
Can the Lynx M20 Pro navigate autonomously without an operator?
Yes. The M20 Pro features onboard SLAM mapping and localization, enabling fully autonomous navigation without GPS dependency. It can perceive terrain in real time, plan routes, and avoid obstacles in all directions using dual 128-channel LiDAR and wide-angle cameras. An optional autonomous charging module further extends unattended operation capability.
How does the hot-swappable battery system work?
The Lynx M20 Pro uses a dual hot-swappable battery system, which means batteries can be exchanged in the field without powering down the robot. Each battery charges in approximately 1.5 hours. This design is critical for continuous operations where downtime between missions is not acceptable.
What is the difference between the M20, M20 Pro, and M20S models?
The M20 Pro offers enhanced specifications compared to the base M20, including a higher payload capacity (36kg vs 15kg standard terrain), upgraded 128-channel LiDAR (vs 96-line), improved IP67 vs IP66 protection, a wider operating temperature range (-30°C vs -20°C), and additional computing power (3 processors vs 2). The M20S specifications are not detailed on this page - please contact sales for a comparison.
Does the robot require assembly or special setup before use?
The Lynx M20 Pro is designed to be deployed by a single operator. No complex assembly is required for standard operation. For specialized payload integrations or autonomous charging station setup, additional configuration may be required. Please contact DEEP Robotics or our sales team for deployment and onboarding support details.
What connectivity and interface options are available?
The M20 Pro includes 24V/72V power input, Gigabit Ethernet, and USB 3.0 external interfaces, as well as RF image transmission for real-time video relay. OTA (over-the-air) firmware updates are supported, and the modular design allows for payload and sensor expansion to meet evolving mission requirements.
