ATN Odin 6 MFT LRF 640x480 Multi-Function Thermal Optic with Rangefinder

Regular price $5,495.00 USD
FREE Shipping!

Pairs well with

ATN Odin 6 MFT LRF 640x480 Multi-Function Thermal Optic with Rangefinder
$5,495.00 USD
Guaranteed Lowest Price Online! - Find a lower price and we'll beat it!
Satisfaction Guaranteed | Need Help? Call (888)-884-2234

Payment and security

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

ATN Odin 6 MFT LRF 640x480 Multi-Function Thermal Optic with Rangefinder


Description

The ATN Odin 6 MFT LRF is a cutting-edge multi-function thermal optic built around ATN's 6th Generation thermal engine, delivering elite performance for hunters, predator control specialists, and serious outdoorsmen. At its core is a 640x480 resolution 12μm VOx uncooled focal plane array with a thermal sensitivity of ≤15mK NETD and a 50Hz refresh rate - providing razor-sharp contrast and smooth heat detection across demanding environments. The integrated laser rangefinder reaches out to 1000 meters with ±1m accuracy, so you can identify, range, and engage targets without ever switching devices.

Powered by ATN's proprietary SharpIR AI image enhancement, the Odin 6 MFT sharpens edge definition and target contrast in real time, making heat signatures stand out even in dense cover or low-visibility conditions. With four modes of operation - clip-on, weapon sight, helmet monocular, and handheld monocular - this single optic handles virtually any field role you throw at it.


Key Features

  • 6th Generation 640x480 Thermal Sensor: 12μm VOx uncooled focal plane array with ≤15mK NETD sensitivity and 50Hz refresh rate for smooth, high-contrast thermal imaging.
  • Built-In Laser Rangefinder (LRF): Eye-safe 905nm Class 1 laser measures distances up to 1000m with ±1m accuracy for instant on-target ranging.
  • SharpIR AI Image Enhancement: Proprietary ATN technology that uses advanced AI algorithms to enhance edge definition and target contrast in real time.
  • Detection Range up to 1700m: High-sensitivity germanium optics and advanced thermal processing reveal heat signatures at extreme distances.
  • Multi-Function 4-in-1 Operation: Operates as a clip-on scope adapter, dedicated weapon sight, helmet-mounted monocular, or handheld monocular - all in one device.
  • 0.37" OLED Display - 1280x1024 HD: High-resolution OLED delivers crisp thermal definition, improved contrast, and faster response times versus standard LCD displays.
  • Ballistic Calculator with 9 Profiles: Automatically adjusts reticle for range and angle; supports up to 9 customizable ballistic profiles for rifles, airguns, and crossbows.
  • 64GB Internal Storage with RAV: Built-in video/audio recording with 64GB internal storage and Recoil Activated Video (RAV) that auto-captures 10 seconds before and after the shot.
  • IP67 Waterproof Rating: Fully sealed against dust and water ingress - built to handle harsh field conditions in any weather.
  • 6 Color Palettes: White Hot, Black Hot, Sepia, Reverse Sepia, High Red, and Low Blue - quickly switch to maximize contrast in any terrain or lighting condition.
  • Picture-in-Picture (PIP) Mode: Zoom in on a target while maintaining a wide-field secondary view for full situational awareness.
  • Hot Point Tracking: Instantly highlights the hottest object in your field of view for faster target acquisition.
  • 5-Year Warranty: Backed by ATN's industry-leading 5-year warranty for long-term peace of mind.

Shipping

Ships free! Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.


What's Included

  • ATN Odin 6 MFT LRF 640x480 Thermal Optic
  • 2x 18650 Batteries
  • Battery Charger
  • USB Cable
  • Lens Tissue
  • Portable Carrying Bag
  • Odin MFT User Manual

Why You'll Love It

The ATN Odin 6 MFT LRF represents one of the most capable thermal optics available to hunters and field professionals today - trusted by those who demand performance when it matters most. Whether you're running predator control on hogs and coyotes, scouting whitetail in total darkness, or operating in challenging low-visibility environments, this optic was engineered to give you a decisive edge. The combination of a high-resolution 640x480 sensor, AI-driven image enhancement, and a built-in laser rangefinder means you're carrying less gear without sacrificing a single capability. Built from magnesium alloy and rated IP67, the Odin 6 MFT is tough enough to handle the abuse of season after season in the field. With 64GB of onboard recording, a 5-year warranty, and four operating modes in one compact package, this is the kind of optic you buy once and rely on for years.


Product Specifications

View Spec Chart
SKU TIMFOD6625LRF
Modes of Operation Clip-on, Weapon Sight, Helmet Monocular, Handheld Monocular
Detector Type 12μm VOx Uncooled Focal Plane Array
Sensor Resolution 640x480
Refresh Rate 50 Hz
Thermal Sensitivity (NETD) ≤15mK
SharpIR AI Enhancement Yes
Non-Uniformity Correction (NUC) Auto / Manual
Lens System 25mm (Ge); F/1.0
Field of View (HxV) 17.5° x 13.2°
Focus Mechanism Manual Focus Controlled by Lens Adjustment
Magnification 1-8x
Digital Zoom 1x, 2x, 4x, 8x
Detection Range 1700 m
LRF Range 1000 m
LRF Accuracy ±1 m
LRF Laser Specs 905 nm, Class 1 (Eye Safe)
Display 0.37" OLED, 1280x1024 HD Resolution
Picture-in-Picture (PIP) Yes
Reticle Styles 7 Styles
Ballistic Reticle Optimized for 5.56x45mm and 7.62x51mm; user-defined reticles supported
Color Palettes White Hot, Black Hot, Sepia, Reverse Sepia, High Red, Low Blue
Eye Relief Unlimited
Diopter Range -3 to +3D
Ballistic Calculator Yes - 9 Customizable Profiles
Hot Point Tracking Yes
Recoil Activated Video (RAV) Yes
Video / Audio Recording Yes
Internal Storage 64 GB
Media Output USB Type-C (Data Transfer, Power Supply)
Geomagnetic + Gyroscope Yes
Standby / Sleep Mode Yes (Shake-to-Wake function)
Startup Time <5 seconds
Battery Type 1x 18650 or 1x CR123 or External USB Type-C (5V DC)
Battery Life ~8 hrs (18650), ~1 hr (CR123)
External Power Supply Yes, 5 VDC/2A, USB Type-C
Material Magnesium Alloy
Mounting Wilcox NVG Shoe Interfaces / Picatinny (MIL-STD-1913) Rail Mount
Button Configuration 5 functional buttons including power
Weight 400g / 0.88 lbs (without battery or eyecup)
Dimensions (L x W x H) 100x75x60 mm (3.94 x 2.95 x 2.36 in)
Max Recoil Rating 4500 Joules / 800g acceleration over 0.3 ms
Working Temperature -46°C to +49°C (-51°F to +120°F)
Waterproof / IP Rating IP67
Warranty 5 Years

Manuals & Guides


FAQ

What are the four ways to use the Odin 6 MFT LRF?

The Odin 6 MFT LRF is designed as a true multi-function optic with four modes of operation: clip-on (mounts in front of your existing day scope), dedicated weapon sight (mounts directly to a Picatinny rail), helmet-mounted monocular (using the Wilcox NVG shoe interface), and handheld monocular for scouting and spotting. This versatility means one optic can serve multiple roles across different hunting or field situations.

How far can the laser rangefinder measure?

The built-in laser rangefinder on the Odin 6 MFT LRF has a maximum range of 1000 meters with an accuracy of ±1 meter. It uses a 905nm Class 1 eye-safe laser, so it is safe to use around people and animals. This allows you to range your target and apply the ballistic calculator simultaneously without carrying a separate rangefinder.

What batteries does the Odin 6 MFT LRF use and how long do they last?

The Odin 6 MFT LRF accepts a single 18650 lithium-ion battery (providing approximately 8 hours of use), a single CR123 battery (approximately 1 hour), or continuous power via USB Type-C at 5V/2A. Two 18650 batteries and a charger are included in the box, so you are ready to go right out of the package.

Can I use the Odin 6 MFT LRF as a clip-on in front of my existing rifle scope?

Yes. The Odin 6 MFT LRF is designed to work as a clip-on thermal device that mounts directly in front of your existing day optic, preserving your familiar reticle and zero. It is compatible with day optics up to 6x magnification. This is ideal for hunters who want to transition from day to night hunting without changing their rifle setup.

Does the Odin 6 MFT LRF record video?

Yes. The Odin 6 MFT LRF has built-in video and audio recording with 64GB of internal storage - no SD card required. It also features Recoil Activated Video (RAV), which automatically records 10 seconds before and after a shot is fired so you never miss a moment. Footage transfers via USB Type-C.

What is SharpIR and how does it improve image quality?

SharpIR is ATN's proprietary AI-powered image enhancement technology. It processes thermal data in real time to sharpen edge definition and improve target contrast, making it significantly easier to identify heat signatures in cluttered environments like dense brush, tree lines, or areas with overlapping heat sources. The result is a cleaner, more defined thermal image compared to standard processing.

Is the Odin 6 MFT LRF waterproof?

Yes. The Odin 6 MFT LRF carries an IP67 waterproof rating, meaning it is fully protected against dust ingress and can withstand temporary immersion in water. It is also rated for working temperatures from -46°C to +49°C (-51°F to +120°F), making it suitable for year-round use in virtually any climate.

Product specifications table
Specification name Specification Value
Battery size 18650
Battery type Rechargeable, Contained-undetachable
Color pattern Black
Material Plastic
Suitable for weapon type Rifle, Shotgun
