ATN BlazeTrek 6 319 Thermal Monocular - 384x288, 2.25-18x
FREE Shipping!
Pairs well with
ATN BlazeTrek 6 319 Thermal Monocular
Description
The ATN BlazeTrek 6 319 is a compact, pocket-sized thermal monocular built on ATN's 6th Generation thermal platform, designed for hunters, scouts, and outdoor professionals who demand high performance without bulk. Powered by a 384x288 VOx uncooled focal plane array with a 12 μm pixel size and an industry-leading NETD rating of 18mK or better, it delivers exceptional sensitivity to even the most subtle temperature differences. With a detection range of 1000 meters and a versatile 2.25-18x magnification range, it handles everything from wide-area scanning to precise target identification.
The BlazeTrek 6 319 pairs its advanced sensor with a crisp 800x600 OLED display, six selectable color palettes, built-in Wi-Fi, and the ATN 6 Connect app - complete with an AI assistant trained on the full product manual. At just 0.7 lb, it rides in your pocket all day and keeps running for up to 8 hours on a single charge.
Key Features
- 384x288 Thermal Sensor, 12 μm Pixel: VOx uncooled focal plane array with a 50 Hz refresh rate delivers smooth, detailed thermal imaging in all lighting conditions.
- NETD 18mK or Better (SharpIR): Exceptional thermal sensitivity picks up the slightest temperature differences for clear, high-contrast imagery - even in challenging environments.
- 2.25-18x Magnification: Digital zoom with 1x, 2x, 4x, and 8x steps plus smooth continuous magnification up to 18x for close-in and long-range use.
- 1000 m Detection Range: 19mm germanium lens (F/1.0) and a 14.4 x 10.8-degree field of view optimized for hunting, surveillance, and wildlife observation.
- 800x600 OLED Display: High-resolution eyepiece display with diopter adjustment (-5 to +5 D) accommodates different users quickly and easily.
- Six Color Palettes: White Hot, Black Hot, Iron Red, Alarm, Green Hot, and Sepia - choose the palette that best suits your environment and preference.
- 32 GB Internal Storage: Record video and capture photos directly to onboard memory; transfer files via USB Type-C.
- Built-in Wi-Fi and ATN 6 Connect App: Stream live view, adjust settings, and manage media from your phone or tablet; includes an AI assistant for instant, manual-based answers.
- Up to 8-Hour Battery Life: Internal rechargeable battery with USB Type-C (5V/2A) external power support keeps you in the field longer.
- IP67 Waterproof, -30°C to 55°C Rating: Sealed against dust and water ingress; operates reliably across extreme temperature ranges from deep winter to summer heat.
- Hot Point Tracking and NUC Modes: Auto, semi, and manual non-uniformity correction plus hot point tracking for dynamic observation tasks.
- Compact and Lightweight - 0.7 lb (320 g): Pocket-ready design that won't weigh you down on long hunts or extended field operations.
Shipping
Ships free! Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.
What's Included
- ATN BlazeTrek 6 319 Thermal Monocular
- USB Cable
- Lens Tissue
- Carrying Case
- Eyecup
- Lanyard
- Wristband
- User Manual
Why You'll Love It
The ATN BlazeTrek 6 319 punches well above its class, delivering professional-grade thermal performance in a package that fits in a jacket pocket. ATN's 6th Generation platform represents a ground-up rebuild of their thermal systems, and the results are immediately apparent in the image quality, app integration, and battery endurance. Hunters and scouts trusted ATN long before thermal imaging became mainstream, and the BlazeTrek 6 continues that legacy with a sensor sensitivity rating that rivals units costing significantly more. The 5-year warranty backs up ATN's confidence in the hardware, giving you long-term peace of mind on a tool you'll rely on season after season. Whether you're glassing a field edge at last light, conducting a property check, or tracking game, the BlazeTrek 6 319 is engineered for dependable, consistent performance in the real world.
Product Specifications
View Spec Chart
| SKU | TIMNBLT319G6 |
|---|---|
| Detector Type | 12 μm VOx Uncooled Focal Plane Array |
| Sensor Resolution | 384x288 |
| Refresh Rate | 50 Hz |
| Thermal Sensitivity (NETD) | 18mK or better |
| SharpIR | Yes |
| Field of View (H x V) | 14.4 x 10.8 degrees |
| Lens System | 19mm (Germanium); F/1.0 |
| Detection Range | 1000 m |
| Magnification | 2.25-18x |
| Focus Mechanism | Manual (1m to infinity) |
| Digital Zoom | 1x, 2x, 4x, 8x |
| Display Resolution | 800x600 OLED |
| Diopter Adjustment Range | -5 to +5 D |
| Color Palettes | White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia |
| Recording | Video |
| Image Capture | Yes |
| Scene Modes | Yes |
| Hot Point Tracking | Yes |
| Standby / Sleep Mode | Yes |
| Built-in Wi-Fi (Hotspot) | Yes |
| Media Output | USB Type-C |
| Internal Storage | 32 GB |
| NUC Modes | Auto, Semi, Manual |
| App Compatibility | ATN Connect 6 - iOS and Android |
| Battery Type | Internal rechargeable |
| Battery Life | ~8 hours |
| External Power | Yes, USB Type-C (5 VDC / 2A) |
| Waterproof / IP Rating | IP67 |
| Working Temperature | -30°C to 55°C (-22°F to 131°F) |
| Dimensions (L x W x H) | 6.20" x 2.23" x 1.98" (158 mm x 57 mm x 50 mm) |
| Weight (with Battery) | 320 g / 0.7 lb |
| Warranty | 5 years |
| Assembly Required | No - ready to use out of the box |
| Shipping Method | Ships in standard parcel packaging; no freight or pallet required |
Manuals & Guides
FAQ
What makes the ATN BlazeTrek 6 319 stand out among budget thermal monoculars for hunting?
The BlazeTrek 6 319 combines a true 384x288 thermal sensor with an NETD rating of 18mK or better, a 50 Hz refresh rate, and ATN's SharpIR image processing - specs that compete well above its price point. Add in 32 GB of internal storage, IP67 waterproofing, an 8-hour battery, and the ATN 6 Connect AI-powered app, and you have a feature set that few units in this price range can match.
What color palettes are available and when should I use each?
The BlazeTrek 6 319 offers six palettes: White Hot (bright objects appear white - versatile all-around choice), Black Hot (inverted, great in warm environments), Iron Red (color gradient for detailed heat mapping), Alarm (highlights the hottest targets in a contrasting color), Green Hot (easy on the eyes for extended observation), and Sepia (warm tones for a natural look). Experiment with a few in your typical hunting environment to find what works best for you.
How does the ATN 6 Connect app work with the BlazeTrek 6 319?
The ATN 6 Connect app connects to the monocular via its built-in Wi-Fi hotspot. Once linked, you can stream a live view to your phone or tablet, remotely adjust settings, capture photos, and record video. The app also features an AI assistant trained on the full product manual, so you can ask questions about zeroing, recording, or settings and get accurate, step-by-step answers without digging through documentation. It is available for both iOS and Android.
Can I use the BlazeTrek 6 319 while it is charging?
Yes. The monocular supports external power via its USB Type-C port (5 VDC / 2A), so you can connect a power bank and run the device indefinitely in the field without interrupting your session. This is especially useful for extended surveillance or all-night observation setups.
Is the BlazeTrek 6 319 waterproof? Can I use it in rain?
Yes. The BlazeTrek 6 319 carries an IP67 rating, meaning it is fully protected against dust and can withstand temporary submersion in water up to 1 meter for up to 30 minutes. Rain, snow, and light splashing are no concern at all - this unit is built for real outdoor conditions.
What is the difference between the BlazeTrek 6 319 and the other BlazeTrek 6 models?
The BlazeTrek 6 lineup varies by sensor resolution and lens focal length. The 319 uses a 384x288 sensor with a 19mm lens (2.25-18x magnification, 1000 m detection). The 325 upgrades to a longer 25mm lens for greater detection range (1300 m) with the same 384x288 sensor. The 619 and 625 step up to a 640x512 sensor for higher image resolution. The 319 is the most accessible entry point while still delivering ATN's Gen 6 platform performance.
