HyperJam Installation Guide

HyperJam

HyperJam 60" & 72" Wall Mount Hoop Installation Guide

Everything you need to safely install your HyperJam Adjustable Wall Mount Basketball Hoop. The installation process is identical for both the 60" and 72" models.

Safety Information

⚠ READ BEFORE INSTALLINGFailure to follow these instructions may result in serious injury, death, or property damage.
  • Consulting a licensed contractor or structural engineer is highly recommended.
  • Minimum three people required for installation.
  • Do not hang or climb on the rim or backboard.
  • Inspect the system before each use.

Before You Begin

Important NoticeWe strongly recommend consulting a licensed contractor or structural professional before installation. The manufacturer assumes no responsibility for damage or injury resulting from improper installation.

Installation Requires

  • 3 capable adults
  • Ability to lift components up to 106 lbs (48 kg)
  • Estimated time: 2-3 hours

Tools Required (Not Included)

  • Hammer drill
  • Appropriate drill bits
  • 4 ft level
  • Tape measure
  • Socket set and wrench set
  • Torque wrench
  • Ladder
  • Safety glasses

Structural Requirements

⚠ CRITICAL: WALL BACKING REQUIREMENTSThe bracket must be anchored to structural backing capable of supporting minimum 1,000 pounds of downforce.
✓ Suitable
  • Solid concrete (min. 4" thick)
  • CMU / cinder block
  • Solid brick (structural)
  • Wood framing 2x6+ studs
  • Steel I-beam or column
✗ Not Suitable
  • Drywall or plaster alone
  • Brick veneer
  • Paneling or siding
  • Hollow-core walls
  • Metal stud framing

Sheetrock / Drywall Walls

Backing required at 88" to 134" from floor. Retrofit: doubled 2"x10" or 2"x12" lumber fastened into 3 studs. Min. 3" thick. 1,000 lb downforce rating required.

Wall Backing Specifications Detailed requirements by wall type — 1,000 lbs downward force capacity minimum FLOOR BACKING BACKING From Floor 134" 88" 16" 16" STUD SPACING & BACKING ZONE BACKING 3" MIN. THICKNESS Screwed or nailed to withstand 1,000 LBS FORCE MINIMUM BACKING THICKNESS

Concrete Walls

8"+ solid concrete at the correct height does not require additional backing. Verify 1,000 lb capacity with a structural engineer.

⚠ DO NOT PROCEED WITHOUT PROPER BACKINGFailure may result in property damage, serious injury, or death.

Assembly Parts List

No. Description Qty
A Wall Frame 1
B Upper Extension Arm 1
C Lower Extension Arm 1
D Spring-Assist Cartridge 1
E Height Actuator 1
F Backboard (60" x 36" or 72" x 42") 1
G Rim 1
H Height Sticker 1

Technical Specifications

Dimension diagram
(A) height range | (B) overhang from wall | (C) bottom of frame from playing surface
Model Backboard Height Range Overhang at 10ft Overhang at 7.6ft Frame Bottom
W-72 72" x 42" 7.5-10 ft 39" 43" 94-1/4"
W-60 60" x 36" 7.5-10 ft 39" 43" 94-1/4"

Installation Steps

1

Mount Wall Frame

  • Measure 83.5" from the playing surface and mark a horizontal reference line.
  • Position Wall Frame (A) aligned to the mark. Level it perfectly plumb and level.
  • Mark anchor hole locations, drill holes, insert wall anchors, then secure frame with 12 sets of washers and bolts.
Wall frame mounting
Wall Frame Mounting Diagram
2

Install Extension Arms

  • Attach Upper Arms (B) to Wall Frame (A) — do not fully tighten yet.
  • Attach Lower Arm (C) to Wall Frame (A). Tighten all while keeping pivot points free.
Upper arm
Upper Arm
Lower arm
Lower Arm
3

Install Height Actuator & Spring Assist

⚠ Do NOT remove the spreader tube on the Spring Assist until the hoop is fully installed.
  • Attach Spring Assist (D) and Height Actuator (E) to Wall Frame (A) and Lower Arm (C) as shown.
Height actuator
Height Actuator & Spring Assist Diagram
4

Install Triangle Brackets on Backboard

  • Attach 4 triangle brackets to backboard using twelve M8x40 bolts, four flat washers, and 12 locknuts.
Triangle brackets
Triangle Bracket Installation
5

Attach Backboard

⚠ Minimum three people required for this step.
  • Crank Extension Arm (C) as low as possible.
  • Attach Backboard (F) to Lower Arm (C) then Upper Arms (B).
Backboard attachment
Backboard Attachment Diagram
6

Rim Assembly

  • Mount Rim (G) with rubber gasket to backboard bracket using hardware #13, #2, #3, #4.
  • Attach spring box cover with #14 and #15. Fix net by twisting loops 90° clockwise.
Rim assembly
Rim & Net Assembly Diagram
7

Apply Height Sticker

  • Crank rim to exactly 10 ft and mark on Height Actuator (E).
  • Apply Height Sticker (H) aligning pencil mark with the 10 ft mark.
Height sticker
Height Sticker Placement

Final Inspection

Do not use if any components appear loose or damaged.

  • All nuts, bolts, and fasteners fully tightened.
  • Wall frame securely anchored and does not move when force is applied.
  • All pivot points move freely without binding.
  • System raises and lowers smoothly through full height range.
  • Rim and backboard are level and properly aligned.

Routine Maintenance

Hardware

  • Periodically inspect and tighten all nuts, bolts, and mounting hardware.

Structural

  • Inspect frame, arms, and brackets for wear or damage. Replace any compromised components immediately.

Rust & Paint

  • Inspect for rust or chipped paint. Clean and touch up as needed. Discontinue use if rust has penetrated structural components.
Replacement PartsUse only manufacturer-approved parts. Contact support for replacements.
