Volt Motions ApexTrail 500 Full Suspension Fat Tire E-Bike - side profile view
$3,399.00 USD
FREE Shipping!
Guaranteed Lowest Price Online! - Find a lower price and we'll beat it!
Satisfaction Guaranteed | Need Help? Call (888)-884-2234

Payment and security

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Volt Motions ApexTrail 500 Full Suspension Fat Tire E-Bike


Description

The Volt Motions ApexTrail 500 is a rugged, full-suspension fat tire electric bike built for riders who demand comfort and capability across every kind of terrain. Powered by a 500W brushless rear hub motor and a 48V 13Ah lithium battery, it delivers smooth, confident electric assistance whether you're commuting through the city, exploring dirt trails, or cruising over snow and sand. The oversized 26" x 4.0" fat tires soak up rough surfaces and provide traction that narrow-tire bikes simply can't match.

With a real-world range of approximately 55-65 km per charge and a torque output of 90-100 Nm, the ApexTrail 500 is built for distance and demanding conditions alike. A Shimano 7-speed drivetrain, front and rear disc brakes, and an integrated downtube battery round out a platform that balances performance, safety, and a clean modern look in one capable all-terrain package.


Key Features

  • 500W Brushless Rear Hub Motor: Smooth and efficient electric assist with 90-100 Nm of torque for urban rides, trail climbs, and off-road adventures.
  • 48V 13Ah Lithium Battery: Long-range power system delivering approximately 55-65 km per charge for daily transportation and weekend rides.
  • Full Suspension System: Front and rear suspension absorbs bumps, trail vibrations, and uneven terrain for a controlled, comfortable ride.
  • 26" x 4.0" Fat Tires: Oversized tires provide exceptional grip and shock absorption across pavement, gravel, sand, snow, and rugged outdoor surfaces.
  • Aluminum Alloy Frame: Lightweight yet durable construction engineered for everyday riding performance and long-term reliability.
  • Shimano 7-Speed Drivetrain: Reliable, smooth gear shifting for climbs, flat cruising, and mixed terrain conditions.
  • Front & Rear Disc Brakes: Dependable stopping power in all weather conditions for improved rider safety.
  • Integrated Downtube Battery: Clean, streamlined frame design with improved weight distribution and a modern appearance.
  • 1-Year Limited Warranty: Covers manufacturing defects, motor and electrical components, and frame structural integrity for residential use.

Shipping

Ships free! Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.


What's Included

  • Volt Motions ApexTrail 500 Full Suspension Fat Tire E-Bike
  • 48V 13Ah Lithium Battery (integrated)
  • Charger

Why You'll Love It

The ApexTrail 500 is engineered for riders who don't want to choose between comfort and capability - it delivers both in a single, well-rounded platform. The full suspension setup means rough trails and pothole-filled streets are absorbed before they reach the rider, making long rides genuinely enjoyable rather than exhausting. Fat tires give you the confidence to ride surfaces that would stop most bikes cold, from sandy beach paths to snow-covered trails. The Shimano drivetrain and disc brakes are trusted components used by cyclists worldwide, so you're getting proven performance where it counts. Whether you're using it for daily errands, outdoor recreation, or long-distance weekend exploration, the ApexTrail 500 is a dependable, capable companion built to handle the demands of real-world riding for years to come.


Product Specifications

View Product Specs
Motor 500W Brushless Rear Hub Motor
Voltage 48V
Battery Capacity 13Ah Lithium Battery
Range 55-65 km per charge
Max Speed Up to 25 km/h
Torque 90-100 Nm
Wheel Size 26 Inches
Tire Size 26" x 4.0" Fat Tires
Frame Material Aluminum Alloy
Suspension Front & Rear Suspension
Gears Shimano 7-Speed Drivetrain
Brakes Front & Rear Disc Brakes
Battery Position Integrated Downtube Battery
Charging Time Over 3 Hours
Load Capacity 100-150 kg
Vehicle Weight 26 kg
Net / Gross Weight 36 kg / 29 kg
Package Size 150 x 28 x 80 cm
Warranty 1-Year Limited Warranty
Assembly Required Yes - partial assembly required upon delivery
Shipping Method Ships boxed via standard freight carrier

FAQ

How far can the ApexTrail 500 go on a single charge?

The ApexTrail 500 delivers a real-world riding range of approximately 55-65 km per charge under normal riding conditions. Actual range may vary based on rider weight, terrain, speed, assist level, and temperature. For the best range, use a lower assist setting on flat terrain and keep tires properly inflated.

Can this e-bike handle snow, sand, and gravel?

Yes. The 26" x 4.0" fat tires are specifically designed to provide traction and stability on soft, loose, and uneven surfaces including snow, sand, gravel, mud, and packed dirt. Combined with the full suspension system, the ApexTrail 500 handles varied terrain with confidence.

Does the ApexTrail 500 require assembly?

Like most e-bikes, the ApexTrail 500 ships partially assembled and will require some setup upon delivery - typically attaching the handlebars, front wheel, pedals, and seat. Basic tools and instructions are generally included. If you are not comfortable with bicycle assembly, we recommend having a local bike shop complete the final setup.

How long does it take to charge the battery?

The 48V 13Ah lithium battery requires over 3 hours for a full charge from empty. For best battery longevity, avoid leaving it on the charger for extended periods after it reaches full charge, and store the battery at a partial charge if storing the bike for an extended period.

What is the weight limit for this e-bike?

The ApexTrail 500 has a listed load capacity of 100-150 kg (approximately 220-330 lbs), making it suitable for a wide range of riders. Always stay within the rated capacity to ensure safe performance and longevity of the components.

What does the 1-year warranty cover?

The 1-year limited warranty covers manufacturing defects in materials and workmanship, motor and electrical component failures under normal use, and the structural integrity of the aluminum alloy frame. It does not cover damage from misuse, accidents, improper maintenance, normal wear and tear, or unauthorized modifications. For warranty support, contact Volt Motions at sales@voltmotions.com.

Product specifications table
Specification name Specification Value
Battery size Built-in battery
Battery type Rechargeable
Bicycle features Built-in front light, Heavy duty brakes, Telescoping seat
Color pattern Black
Gearing type Chain
Material Aluminum
